1200x 12MP High Power Digital Microscope Pcb Polarizing With Metal Stand

Product Details:
Place of Origin: China
Brand Name: Toproview/Neutral/Customization
Certification: CE/FCC/RoHS
Model Number: DM042
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Neutral/Customization Giftbox/16pcs per carton
Delivery Time: 5~35 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 50000pcs/month
  • Detail Information
  • Product Description

Detail Information

Model: DM042 Polarizer LCD Microscope Adjustable Magnification: 10x ~ 250x
Max.magnification By Digital Zoom: Up To 1200x Supported Operation Systems: Windows 7/8/10,macOS 10.14 And Above
Connection Type: USB 2.0/HDMI Port /TV Port PC Software With Measurement: Yes
High Light:

12MP High Power Digital Microscope

,

1200x Digital Microscope Pcb

,

1200x High Power Digital Microscope

Product Description



1200x 12MP High Resolution LCD Digital Microscope Polarizing with Metal Stand



PRODUCT DESCRIPTION

Main Features

* Polarizer build in: allows to reduce reflection, very usefual for observing objects with shiny surface like diamond, jewelry, metal etc.,

* Features HDMI output enabling the microscope to be connected with external monitors, giving user the unexpected experience of viewing and photographing.



Quick Details

Toproview DM042 is built-in 4.3 inch LCD screen, with assembled adjustable polarizer for reflective object. Support HDMI & TV output, provide user the larger and clear visual experience. Also support USB output for PC connection and to work measurement software.

Different from other LCD digital microscope in the market, LCD digital microscope built-in polarizer switch, do not need extra light filling to the reflection on observation surface, which will make the working more convenient and more efficent.



LCD DIGITAL MICROSCOPE SPECIFICATIONS

MODEL

Model Name

DM042



Connection

USB 2.0 to PC/HDMI port to monitor/TV port to monitor

OPTICS

Polarizer

Yes



Magnification

Real 10x~250x(based on 21 inch Display)



Lens type

Optical glass



Focus range

Manual focus 0~110mm



Illumination

8 adjustable white LED

SENSOR

Sensor type

CMOS



Size

5 megapixel



Resolution

2590*1944



Frame rate

25 fps at 5MP output;
35 fps at 2MP output

FEATURES

Software

DigiCapture Pro for
Windows/MacOS



Measurement function

Yes



Certification

CE/FCC/RoHS

PHYSICAL

Dimensions

18*34*30cm



Gross weight

0.2kg



Stand

Comes with metal stand



1200x 12MP High Power Digital Microscope Pcb Polarizing With Metal Stand 0

1200x 12MP High Power Digital Microscope Pcb Polarizing With Metal Stand 1



FAQ

Q:Why choose Toproview microscopes?

Toproview: If the selection of products do not meet your needs, custom options are available.

Q:Why choose Toproview microscopes?

Toproview: Developed for professionals yet economical for consumer or casual use.
