220X Usb Microscope With Uv Light 1280x720 WiFi Microscope 2 Mega Pixel Sensor

220X Usb Microscope With Uv Light 1280x720 WiFi Microscope 2 Mega Pixel Sensor

Toproview 220X Usb Microscope

Microscope With Uv Light 1280x720 WiFi

2MP Usb Microscope Toproview

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Product Name:
DM023B UV WiFi Microscope
2 Mega Pixel
Connection Type:
WiFi/ USB Port
Dimmable Illumination:
4pcs UV LED+4pcs White LED
Payment & Shipping Terms
Minimum Order Quantity
Packaging Details
Neutral/Customization Giftbox/16pcs per carton
Delivery Time
5~35 working days
Payment Terms
L/C, T/T, Western Union, D/A, D/P
Supply Ability
Product Description


Mobile Compatible Handheld UV Light Microscope with True High Quality 2 Mega Pixel Sensor


Main Features

* Image and video resolution: 1920x1088/1280x720/864x480.

* Max. Frame is up to 25 fps at the highest resolution 2MP, that means you will get the smooth video even in the high resolution without any stuck and stop.

* Support to output through WiFi and USB connection, which is with the wonderful compatibility with smart devices like iPhone, iPad, Android; Windows computer; Macbook etc.,

* Digital zoom by microscope is available, user can zoom out or zoom in to see the partial view with this function.

* With SD card slot on microscope body, support SD card storage up to 32G. User can use the microscope with or without SD card inserted. The SD card slot is designed for people who is required the data transmission but not in the good network status.

220X Usb Microscope With Uv Light 1280x720 WiFi Microscope 2 Mega Pixel Sensor 0

220X Usb Microscope With Uv Light 1280x720 WiFi Microscope 2 Mega Pixel Sensor 1



MODEL Model Name DM023B
  Connection WiFi to smart devices; USB 2.0 to PC
OPTICS UV light Yes
  Magnification Real 10x~200x
  Lens type Optical glass
  Focus range Manual focus 0~110mm(with stand)
  Illumination 8 adjustable LEDs(white + purple)
SENSOR Sensor type CMOS
  Size 2 megapixel
  Resolution 1920*1080
  Max.Frame rate 25 fps at 2MP output
FEATURES APP TopScope Pro for iOS/Android (customizable)
  Software DigiCapture Pro for Windows/MacOS (customizable)
  Measurement function(PC Software) Yes
  Supported operation systems
(Smart device)
iOS 12.0 or later Android 4.2 or later
  Supported operation systems
Windows 7/8/10macOS 11.2.1 or above
  Capturing by microscope Yes with recording button on microscope
  Recording by microscope Yes with digital zoom button on microscope
  Certification CE/FCC/RoHS
REPLACEABLE BATTERY 18650 Lithium-Ion Battery 2000mAh rechargeable and replaceable
  Battery working time Continue working for 2.5 hours
  Charging time 2.5hrs (when WiFi Digital Microscope power off)
PHYSICAL Body dimensions 16.6*4.5*4.0cm
  Gross weight 0.2kg
  Stand metal stand for neutral product; support to customize



* DM023B Handheld UV Light Microscope can be used in beauty salons, beauty chain agencies, cosmetics distribution sales, beauty products distribution sales, skin care products distribution sales, health products distribution sales, personal and family self-test and so on! Choosing a suitable cosmetic skin analyzer can improve the scientific basis of analysis, the quality of service and the efficiency of work, giving consumers a better experience.

* Fiber and textiles check

* Cosmetic effects corroboration

* Laboratory and classroom research

* Field use for agricultural close quality control

* Mineral prospections

* Education and on-site classroom demonstrations.
