Shenzhen Toproview Technology Co., Ltd

5MP Polarizer USB Digital Microscope With Measurement Function Real 250x

Product Details:
Place of Origin: China
Brand Name: Toproview/Neutral/Customization
Certification: CE/FCC/RoHS
Model Number: DM022C
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: Neutral/Customization Giftbox/16pcs per carton
Delivery Time: 5~35 working days
Payment Terms: L/C, T/T, Western Union, D/A, D/P
Supply Ability: 50000pcs/month
  • Detail Information
  • Product Description

Detail Information

Polarizer: Yes Sensor Resolution: 5M Pixels
Max. Frame: 25fps At 5MP Photo & Video Resolution: Optional 5MP/4MP/3MP/ 2MP/1.3MP
Adjustable Magnification: 10x~250x Connection Type: USB 2.0 To PC
High Light:

5MP Polarizer USB Digital Microscope

,

250x Digital Microscope With Measurement

,

250x USB Digital Microscope

Product Description



5MP Polarizer USB Digital Microscope with Measurement Function Real 250x



Quick Details

With both 5MP resolution and polarizer filter in the same product, users will get the incredible high quality mutifunctional USB microscope for the wide applications.

With this unit you may see a unique & “bigger” world. All those excellent features make it a good aid for your daily inspection on tiny objects.



Main Features

* PC Software with 16 optional languages can reach most of the uses in the worldwide.

* Light source is the dimmable LED ring illuminator (8pcs SMT White LED).

* Max frame rate is up to 25fps at 5MP output, user can get the super high quality and smooth viewing and recording.

* Image sensor is the high resolution 5M pixels; with real 250x magnification but not interpolation.

PRODUCT SPECIFICATIONS

MODEL

Model Name

DM022C



Connection

USB 2.0

OPTICS

Polarizer

Yes



Magnification

Real 10x~250x(based on 21 inch Display)



Lens type

Optical glass



Focus range

Manual focus 0~110mm



Illumination

8 adjustable white LED

SENSOR

Sensor type

CMOS



Size

5 megapixel



Resolution

2590*1944



Frame rate

25 fps at 5MP output;
35 fps at 2MP output

FEATURES

Software

DigiCapture Pro for
Windows/MacOS



Measurement function

Yes



Certification

CE/FCC/RoHS

PHYSICAL

Dimensions

18*34*30cm



Gross weight

0.2kg



Stand

Comes with metal stand



5MP Polarizer USB Digital Microscope With Measurement Function Real 250x 0

5MP Polarizer USB Digital Microscope With Measurement Function Real 250x 1



FAQ

Q: Can you accept OEM or ODM?

A: Yes, OEMand ODM are welcome. We have the fully ability to customize any design, shape and size as per customer’s specific requirements.

Q: What certificate do you have?

A: For all products we supply CE, FCC, RoHs.

Q:How could I get samples?

A: We support sample test before bulk order, contact me for more details just now!
