250x Magnification Polarizer USB Digital Microscope Compatible With Mac And Windows For Jewelry Inspection Microscope
1: Connected to the devices , you can use the Windows software’s measurement function to measure .
2: Support taking photos and recording videos and measurement function only works on Windows.
3: The image quality is high: you get up to 5Mpx images and 5Mpx videos.
Product Specification:
| Model | Model Name | DM022C |
| Features | Connection | USB 2.0 to PC |
| Image Sensor | 5 Megapixel 1/3.2" CMOS Image Sensor | |
| Photo And Video Resolution | 5MP / 4MP / 3MP / 2MP / 1.3MP | |
| Magnification Ratio | Real 10x~250x(Based On 21 inch Display) | |
| Max.Frame Rate | 25 fps at 5MP Output | |
| Light Source | 8Pcs SMT White LED | |
| LED Brightness Adjustable | Yes | |
| Focus Range | From 0mm to 55mm on metal stand | |
| Lens Type | Optical Glass | |
| Advantage | Switchable Polarizer | Yes |
| Brand Name | Toproview / Neutral / Customization | |
| Customized Support | OEM / ODM / OBM | |
| Certification | CE / FCC / RoHS | |
| Focus Mode | Manual Continuous Focus | |
| Warranty | 1 Year | |
| Software | PC Software | DigiCapture Pro (Customizable) |
| PC Software Supported Operation Systems | Windows 7 / 8 / 10 , macOS 11.2.1 or above | |
| PC Software OSD Language | There Are 16 Languages Built In The Software | |
| PC Software With Professional Measurement | Yes | |
| PC Software Support Four Display Concurrently | Yes | |
| PC Software Support Photo,Video Recording,Timed Photo And Timed Video | Yes | |
| PC Software Support Plug and Play | Yes | |
| Package details | Accessories | CD, USB cable,calibration ruler,metal stand |
| Body Dimension | 110x35x25mm | |
| Gross Weight | 0.06KG | |
| Gift Box | 22*16*9cm | |
| Gross Weight | 0.6KG | |
| Carton Box | 46.5*33*37.5cm | |
| Gross Weight | 10.5KG | |
| Carton | 16Pcs |
Product Advantages:
1: Portable magnification is a useful and funny microscope for students, engineers, inventors, and others who need to magnify and explore the micro things.
2: Our USB Ditital Microscope is a great science tool for educational purpose, personal interests and research.
3: Empowered with USB 2.0 interface, our usb type microscopes support connecting through USB to Windows or macOS computer to observe
Product picture:
Before Polarizer Adjustment
After Polarizer Adjustment
